TechnoSonus V100 Band
Product Description
TechnoSonus V100 Band is a vibration cushioning material based on elastic glass-fiber mat. The product is used as acoustical uncoupling for frame and frameless soundproofing system mounting and as acoustic lining under timber floors. The fiber pattern and porous structure of the glass-fiber mat impart unique damping properties to the band with the vibroacoustic characteristics being retained under dynamic stresses and dead-weight loads.
Composition
- fiberglass
| Title | TechnoSonus V100 Band | TechnoSonus V150 Band |
|---|---|---|
Length, m | 30 | 30 |
Width, mm | 100 | 150 |
Thickness, mm | 4 | 4 |
Weight, kg | 1 | 1.5 |
Roll Area, m2 | 3 | 4.5 |
| Title | TechnoSonus V100 Band |
|---|---|
Surface Density, kg/m2 | 0.3 |
Dynamic Modulus under 2kPa, MPa | 0.18 |
Dynamic Modulus under 5kPa, MPa | 0.35 |
Compression Strain Index under 2 kPa | 0.25 |
Compression Strain Index under 5 kPa | 0.35 |
| The size | TechnoSonus V100 Band | TechnoSonus V150 Band |
|---|---|---|
Package | roll | roll |
Roll Diameter, mm | 310 | 310 |
Roll Width, mm | 100 | 150 |
Roll Volume, m3 | 0.0075 | 0.011 |
Roll Weight, kg | 1 | 1.5 |
Euro Trailer Loading Capacity, roll | 10933 | 7455 |
Euro Trailer Weight at Complete Load, kg | 11000 | 11000 |
Storage period is 35 months, subject to storage and transportation conditions.
After the warranty period of storage has expired, the products must be checked for compliance with the declared characteristics and, if they comply with the declared characteristics, the period of storage may be extended.
Products shall be stored in dry, ventilated warehouses, at a distance of at least 1 m from heating and heating devices, at an air temperature not lower than -40°C and not higher than +40°C and a relative air humidity of 60-80%.
When transporting, loading, unloading and storing it is necessary to ensure safety from impacts, damage, contamination and moisture. Transportation of the Band is carried out in a horizontal position.
When storing, avoid mechanical damage and high pressure, protect from exposure to UV rays.
The product is delivered item-by-item in shrink wrapped rolls. Palletized delivery is also possible.
